中文版Separate zipper
specification：Technical specifications of 8#sparate zipper
Testing item
Unit
Enterprise Standard
Slider fastener breadth
mm
70mm
Chain width
mm
7mm
Chain tension strength
N/in
Minimum: 400N/in
Slider action docking
N
Minimum: 175N
Slider block break strength
N
Minimum: 450N
Airproof performance test
Kpa
Minimum: 200Kpa
Slip strength
N
Maximum: 55N
Reciprocating times
Cycle
Minimum: 500times
Note:
1) The chain tension strength testing method is to select a section of the zipper not less than 60mm and nip 25mm from the section. The distance from top to chain element should not exceed 10mm and the slide velocity should be 110mm/min.
2) Reciprocating tests require the zipper length within 1.0m and slide velocity within 10-15m/min.
3) Please specify your special requirements for usage when ordering the products.
